Yard Armor SnapDragon I and II

---

Length: 6 ft. / 7 ft. / 8 ft.

Width: 7.5”

Weight: 11.7 lbs. / 13.6 lbs. / 15.6 lbs.

Material: galvanized steel

Installs in seconds - no tools required.

Permanent, wind resistant design.

Powder coated for durability.

Color and texture options to achieve your desired affect.

Special orders are available for odd size lengths. (15% surcharge)

Weather, string trimmer, and rodent resistant.

Patents Pending.

The SnapDragon I™ shield is designed for attachment to 2-3/8” diameter steel poles having Simpson® PGT Type brackets.

The SnapDragon II™ shield is for use with all other bracket systems.

1. Allow 1-2 inches at the bottom of the pole for drainage, string trimming, and soil swelling.

2. CAUTION!

SHARP EDGES!  WEAR GLOVES!  PINCH POINT!

DO NOT PUT YOUR FINGERS BETWEEN THE SHIELD AND THE FENCE CROSS MEMBERS!

3. Align the top of the shield with the top of the pole.

4. With both gloved hands on the front the shield, opposite to the top bracket, press hard until the shield snaps over the brackets. The shield will snap on when approximately 40 lbs. of pressure is applied.

WARNING – DO NOT HAMMER ON THE SHIELD.  HAMMERING WILL DENT THE SHIELD.

5. Move to the next bracket down. Again, with both hands on the front of the shield, and press hard.

 1. What holds the SnapDragon™ shield in place?

The shield is held in place by the potential elastic energy you exert when you push it into place, which continues to pull the Snap Dragon shield against the fence.

2. Why is it hard to press the SnapDragon into place?

Because the SnapDragon shield is designed to remain in place during very high wind and storm conditions.

3. What if when installed, it is not aligned with the top of the pole?

The SnapDragon shield can be moved upwards along the pole with a crowbar or other lever placed at the bottom of the shield. Use a wide lever to avoid creating a dent at the bottom of the shield.
